O’Donnell Custom Hand-wound Pickups. Built to classic Tone specifications , Nickel silver covers and base plates,Original 1.97” pole spacing , plan Enameled AWG 42 & AWG 43 wire, Choice of Alnico 5 & Alnico 2  Magnets, All slug coils on O’Donnell Pickups are slightly over wound to give distinct clarity to the Mid range.

  1. Modern Humbucker   A5 Chrome Cover


Alnico 5 magnets AWG 43 gauge wire. Nickel silver base plate,extra winding on coil slug, waxed potted, Four wire conductor plus ground.


12.0k Bridge

8.0K Neck                        $120.00 Each



  1. Vintage Traditional  PAF Humbucker   A2 Chrome Cover


Alnico 2 magnets AWG 42 gauge wire. Nickel silver base plate with timber shims fabric taped and waxed potted, braided 2 wire conductor.


8.0k Bridge  - 2.015 pole spacing

7.0K Neck   -1.97 pole spacing


$125.00 Each

  1. Modern Humbucker   A5   Black/Zebra


Alnico 5 magnets, AWG 43 gauge wire. Nickel silver base plate,fabric taped and waxed potted, Four wire conductor plus ground. with high quality magnets. Pickup Surrounds sold separately Pickup only.


12.0k Bridge -2.015 pole spacing

8.0K Neck-1.97 pole spacing

   $110.00 Each

Phone 03-9555-1121 or Email for Enquires and sales, full warranty on all pickups, Free freight fees Australia Wide  sales@odonnellguitars.com

  1. Vintage Humbucker   A5 Chrome Cover


Alnico 5 magnets AWG 42 gauge wire . Nickel silver base plate,extra winding on coil slug, waxed potted, Four wire conductor plus ground.


9.0k Bridge  2.015 pole spacing

8.0K Neck     1.97 pole spacing


$120.00 Each



  1. Humbucker  Modification Magnet Change

Improve Pickup Quality of a cheaper pickup with this modification. changing the magnet to a quality Alinico 5 or Alinico 2 magnet adds better clarity and Tone. USA Magnets.



$45.00 per Pickup.

Guitar ModelsODonnell_Custom_Guitar__handmade_guitars_Models.html

Guitar Parts Sales

P90 Soap Bar Single coil

model code- PA5 modern Spec


2 x Alnico 5 magnets AWG 42 gauge wire  scatter wound . fiber bobbin, unpotted , 2 wire cloth braided Wire. 50mm pole spacing


8.8K  ohm resistance                      $110.00 Each


Black or cream Covers

P90 Soap Bar Single coil

model code- PA2 Vintage 50s Spec


2 x Alnico 2 magnets AWG 42 gauge wire . plastic bobbin, wax potted  2 wire cloth braided Wire. scatter wound. 50mm pole spacing



8K ohm resistance                        $110.00 Each


Black or cream Covers

Home PageODonnell_Custom_Guitars_guitar_setup_repair_melbourne_.html

Full Purchase Refund No Questions asked within 14 days of purchase if you are not completely happy with your pickup choice ,we refund your money . freight charges and returns are at the buyers expense , full purchase price of pickups is returned at customer request. immediate refund transfer only when items have been returned.

Cryogenic Treated - The process has a wide range of applications from industrial tooling to improvement of musical signal transmission. Some of the benefits of cryogenic treatment include longer part life, less failure due to cracking, improved thermal properties, better electrical properties including less electrical resistance, reduced coefficient of friction, less creep and walk, improved flatness, and easier machining.
